iav rau PV daim ntaub ntawv

Kev Ua Haujlwm ntawm Hnub Ci Vaj Huam Sib Luag

Lub hnub ci vaj huam sib luag iav ua ob peb lub luag haujlwm tseem ceeb rau hnub ci vaj huam sib luag, suav nrog:

Kev tiv thaiv los ntawm kev puas tsuaj -Tempered hnub ci vaj huam sib luag iav yog ib txheej tiv thaiv rau lub hnub ci vaj huam sib luag, tiv thaiv ib puag ncig yam xws li vapors, dej, thiab av los ntawm kev puas tsuaj rau cov cell photovoltaic. Tempered hnub ci vaj huam sib luag iav kuj muab siab zog, zoo heev transmissivity, thiab tsis tshua muaj kev xav.

Durability thiab kev nyab xeeb -Tempered iav muaj txog li plaub npaug ntawm lub zog ntau dua li cov iav txheej txheem. Lub zog no yog qhov tseem ceeb vim tias lub hnub ci vaj huam sib luag pem hauv ntej yuav tsum muaj kev tiv thaiv ntev tiv thaiv cov khoom. Ua tsaug rau cov txheej txheem thermal thiab tshuaj uas tsim cov iav tempered, nws tseem hu ua toughened lossis iav kev nyab xeeb. Tempered iav muaj kev nyab xeeb dua rau kev siv vim tias nws tawg rau hauv ntau qhov me me thaum tawg, txo qhov tshwm sim ntawm kev raug mob.

Luj —Cov iav yuav tsum yog ib qho hnyav rau hnub ci vaj huam sib luag. Kev lag luam tus qauv hnyav rau 3.2 hli tuab hnub ci vaj huam sib luag iav yog nyob ib ncig ntawm 20 kg. Tempered iav tuaj yeem muab qhov hnyav yam tsawg kawg nkaus no, zam kev phom sij ntawm pheej yig, lub teeb ci hnub ci vaj huam sib luag iav.

Hom Solar Vaj Huam Sib Luag

Lub hnub ci vaj huam sib luag iav yuav muaj ob hom tseem ceeb: nyias-zaj duab xis lossis crystalline. Ob leeg muaj cov yam ntxwv sib txawv kom nco ntsoov.

Thib-Film -Nyias-film iav yog lub teeb yuag, tus nqi tsim nyog, thiab yooj yim rau nruab. Lawv yog tsim los ntawm tus qauv, tsis-tempered iav thiab tuaj yeem ua nyias li 2.5 hli. Nyias-film solar panels yog lub teeb yuag vim lub iav npog lub vaj huam sib luag tsis muaj thav duab. Lawv xav tau qhov chaw tshaj plaws thiab muaj qhov ua haujlwm qis tshaj plaws ntawm txhua qhov kev xaiv ntawm lub hnub ci vaj huam sib luag iav.

Crystalline -Hnub ci vaj huam sib luag ua nrog crystalline iav zoo li muaj qhov tuab ntawm 3 mus rau 4 hli, uas ntxiv kev ruaj ntseg ntxiv. Cov iav no muaj qhov tshwj xeeb ntxhib nto, uas ua rau lub iav sib txuas zoo nrog lub vaj huam sib luag EVA zaj duab xis rau lamination lub hom phiaj. Cov iav du tuaj yeem ua rau maj mam delamination. Muaj ob hom iav crystalline: monocrystalline thiab polycrystalline. Ob leeg ntawm cov crystalline panels xav tau ib txoj kev fabrication uas yuav ua tau silicon crystals uas txiav mus rau hauv nyias wafers siv nyob rau hauv lub hnub ci vaj huam sib luag iav.

Monocrystalline -Cov vaj huam sib luag no muaj lub ntsej muag zoo nkauj thiab pom kev ua haujlwm zoo, tab sis lawv kim kim dua li cov iav polycrystalline.

Polycrystalline -Cov no tsis tshua kim tshaj li lawv cov monocrystalline counterparts, ntawm tus nqi ntawm kev txo qhov muag pom kev thiab kev ua haujlwm zoo.
