Dab tsi yog qhov txiaj ntsig ntawm Insulated Glass

Insulating iav yog ib qho ua ke ntawm ob los yog ntau tshaj ntawm cov iav nrog ib txheej ntawm inert gas, piv txwv li argon los yog krypton, sandwiched ntawm lawv. Ob lub iav ntawm iav yog ntxiv sib cais los ntawm ib qho txhuas spacer nrog qhov nyob hauv nws; ib qho desiccant, uas tej zaum yuav yog silica gel los yog zeolite, yog siv hauv qab cov khoom siv los nqus cov dej noo uas tuaj yeem tshwm sim ntawm cov iav panes. Lub sealant tseem ceeb yog siv sab hauv los txhawm rau txhawm rau txhawm rau txhawm rau sab hauv ntawm lub vaj huam sib luag glazing, thaum lub sij hawm thib ob silicone sealant yog siv sab nraud los tsim lub foob airtight raws qhov txuas txuas ntxiv ntawm lub qhov rais.

Qhov kev npaj no feem ntau hu ua IG unit lossis insulated glazing unit. Lub thickness ntawm lub iav yog li ntawm 5 hli mus rau 12 hli thiab lub inert gas txheej ntawm lub panes yog 12 hli tuab.

Cov txiaj ntsig ntawm insulating iav

1. Lub ntsiab kom zoo dua ntawm insulating iav yog tias nws yuav pab kom insulate los ntawm kev txo cov cua sov thiab cua sov. Qhov sib ntxiv ntawm ntau txheej ntawm iav nrog cov roj muab tub lim ntxiv tiv thaiv qhov rais thiab cov tsev los ntawm kev poob cua sov.

2. Lwm qhov zoo ntawm cov iav insulating yog tias nws ua kom lub zog ua haujlwm ntawm lub tsev. Qhov txo qis ntawm cov hluav taws xob hloov hluav taws xob txo cov hluav taws xob uas yuav tsum tau ua kom sov lossis txias qhov chaw. Qhov no txo ​​qis cov nqi hluav taws xob, tshwj xeeb tshaj yog nyob rau hauv qhov kub thiab txias heev. Kev siv qis-e glazing thiab reflective coatings tuaj yeem txhim kho qhov ua tau zoo ntawm qhov rais los ntawm kev txwv kev hloov hluav taws xob ntxiv.

3. Insulated glazing kuj tseem txhawb lub suab rwb thaiv tsev thiab txhim kho lub suab nrov ntawm qhov chaw. Cov roj inert tam sim no nyob nruab nrab ntawm ob lub iav ntawm iav tsis tso suab nrov dhau los thiab ua qhov cuam tshuam ntawm lub suab nrov tam sim no hauv lub tsev thiab qhov tam sim no sab nraum lub tsev.

4. Tus nqi ntawm lub hnub ncaj qha thiab UV rays nkag mus rau hauv chav los ntawm lub qhov rais yog txo. Qhov no tiv thaiv kev ploj ntawm cov duab, duab, duab, ntaub, ntaub pua plag thiab ntaub sofas tsis tshwm sim los ntawm UV cuam tshuam ntawm lub hnub lub rays.

5. Insulated iav qhov rais kuj siv tau raws li kev ruaj ntseg thiab kev ruaj ntseg qhov rais. Kev tawg cov iav insulated yog qhov nyuaj thiab siv sijhawm ntev dua nrog ib lub qhov rais pane.

Yuav ua li cas insulated iav sib dhos?

Insulating iav, tseem hu ua ob chav glazing, yog sib sau ua ke hauv cov kauj ruam hauv qab no.

Laminated los yog toughened iav muaj ib tug tuab nyob rau hauv qhov ntau ntawm 3mm thiab 10mm yog siv los tsim ib tug ob chav glazed qhov rais qhib. Ob lossis peb lub panes yog siv los tsim ob lossis triple glazed qhov rais.

Muab ob npaug los yog triple glazed panes ntxiv sib cais los ntawm "spacers". Spacer txhais tau tias yog ib qho ntawm cov hlau uas cais cov iav ntawm cov iav nyob rau hauv ib qho insulated glazing system nyob rau hauv thiaj li yuav tsim ib tug foob nyob rau hauv lub gas qhov chaw ntawm lawv.

Lub spacers yog drilled nrog lub qhov thiab ntim nrog ib tug desiccant xws li silica gel. Lub desiccant pab nqus txhua hom dej vapor uas yuav muaj nyob hauv qhov sib txawv. Tom qab ntawd cov qhov no raug kaw nrog lub sealant.

Cov iav panes tam sim no tau muab tso rau ntawm ib sab ntawm lub spacer strip thiab nias nrog lub tshuab nias tsis siv neeg.

Cov kauj ruam kawg yog siv lub sealant rau sab nraud ntawm ob chav glazed panels. Tom qab ntawd cov iav insulating yog npaj txhij.
